For those who need a bit more…
YGE Opto 255 and Opto 255 Navy!
For special high current applications like big gliders with impeller, jets, big planes, boats, speedhelis and industry we developed the YGE Opto 255. 255A continuous and 400A burst are no problem for this ESC. It has integrated antispark and full telemetry integration like all latest YGE speedcontrollers. A highlight is the full isolation of all signals (telemetry, RPM and other interfaces, too) via optocouplers. next to the typical RC interfaces many industrial interfaces like for example CAN-Bus can be implemented. Ofcourse the Opto 255 has the innovative RCT cooling design and the intelligent current-measuring and current limit, which provides a cool and safe operation without any hard cutoffs. The Navy version has a special watercooling case and bigger capacitors.
- 255A continuous / 400A peak
- 6 to 16S LiPo
- All signals isolated by optocouplers for best noise immunity
- integrated antispark
- dimensions: 105 x 54 x 32mm (Navy: 119 x 54 x 31mm)
- weight with all cables: 343g (Navy: 365g)
- cable diameter battery/motor: 8² / 8²
- temperature-driven 12V-fan included
- Different interfaces for individual signal processing
YGE 205 HVT Black Edition!
for 2021 we have something special…
- 205A continuous / 270A peak
- 6 to 14S LiPo
- BEC: 12A continuous / 30A peak
- Weight without/with cables: 219g/287g
- Dimensions: 84 x 54,5 x 33mm
- cable diameter battery/motor: 6²/6²
Price: 569,-€
New ESC types: YGE Saphir 125 & Opto 135!
Saphir 125:
- Now with new RCT-cooling
- Same technical specs as the big brother, Saphir 155
- 4-8s Lipo
- Adjustable Power BEC with 10A continuous and 25A Peak
- BEC current is now measured and shown in the telemetry
- Capacitor temperature is now measured and shown in the telemetry
- Current limit adjustable up to 200A, perfect for high peaks in helicopters
- thin and flatdesign to fit into small plane and glider fuselages
- capacitors are almost completely enclosed by the case to be more resistant
- True 125A continuous!
- 4,5mm thinner and 6mm flatter than the 135LVT!
- dimensions with capacitors: 76,5×34,5×19,5mm
- weight with cables: 124g
Opto 135:
- HV-ESC (up to 12s) with optocoupler, without BEC
- Now with new RCT-cooling
- three-piece case design like the YGE Aureus 135
- versatile connectors allow many different interfaces for special- or industrial-applications such as CAN, potentiometer control or Prop-positioning (on demand)
- dimensions with capacitors: 82×43,5x26mm
- weight with cables: 155g
Both ESCs are available soon.
Ofcourse, the 135LVT and 120HVT will still be supported with updates and service in future.
NEW!
YGE 205 HVT - V2
New Features:
- improved case-design with optimized cooling
- 1,5mm narrower
- The mounting holes are now compatible to common helicopters (distance between holes 43mm)
- dimensions: 84 x 54,5 x 33mm
- weight with cables: 287g
- price: 499,-€ (incl. fan)
NEW!
YGE Aureus 135
– 6-12s LiPo
– BEC 10A continuous, 25A Peak
– pluggable receiver-, and telemetry-cables
– 32-Bit Processor
– new RCT-cooling system for lower temperatures and smaller dimensions
– super slow startup for scale-helicopters possible (up to 60 sec.)
– high precise current measuring and
adjustable current-limit
