News

Be sure to have a closer look at our new products and stay up to date.

New Firmware V1.03370!

  • active freewheel improved
  • Autotiming improved
  • Switching between RPMs in Governor-mode now softer
  • current limit for 95LVT now 150A (Max. 160A)
  • current limit for 135LVT now 170A (Max. 190A)
  • Graupner HoTT telemetry: current-, voltage- and temperature alarms now don't repeat if the value isn't critical anymore
  • Jeti ExBus telemetry: In some cases telemetry values could freeze by using assist-receivers. This is fixed now.

New Firmware V1.03300 for all ESC-types!

  • Now it is possible to change the adresses or disable telemetry-values with Multiplex-telemetry
  • capacity-resolution: now 1mAh steps (Graupner still 10mAh steps)
  • Now it is possible to set alarms for capacity, current and voltage in the PC-software for Multiplex and Graupner telemetry

Caution! For some functions it is necessary to use the latest PC-software. We recommend to download the latest PC-software from www.yge.de.

Please make sure that your ESC doesn't already have the latest firmware before the update-request, because the last batches were already shipped with the V1.03300.

YGE 135LVT & YGE 120HVT Opto now in black/blue

IMG_7294

NEW!

YGE Aureus 135

- 6-12s LiPo
- BEC 10A continuous, 25A Peak
- pluggable receiver-, and telemetry-cables
- 32-Bit Processor
- New RCT-cooling system for lower temperatures and smaller dimensions
- super slow startup for scale-helicopters possible (up to 60 sec.)
- High precise current measuring and
adjustable current-limit

NEW!

YGE 205HVT +BEC!

Highlights:

  • Now with BEC! 5,0V - 8,4V   12A continuous, 30A Peak
  • 6 bis 14s LiPo
  • 32-Bit Processor
  •  Telemetry compatible with: Graupner HoTT V4, Mikado VBC, Jeti ExBus, Multiplex MSBV2, MSH Brain2, Spirit FBL
  • Telemetry via TexY: Futaba SBUS2, Spektrum XBUS, FrSky S.Port
  • Super slow softstart for Scale-helicopters possible (60 sec.)
  • pluggable receiver- and BEC-cables
  • ultra precise current measurement and current limiting

Now available!

Texy-Werbung

F3A-Brake

In this video, you can see how to program the Acro-brake:

NEW!

YGE 135LVT *V2*

IMG_0102

News:

- New case-design with better cooling
- 15g lighter and 3mm lower than the V1
- Master- slave- and telemetry-cable pluggable
- Higher BEC-rating (10 continuous, 22A Peak)
- fan with JST-plug enclosed

NEW!

YGE 165HVT & 205HVT

News:

- 205HVT in aluminium-case
-165HVT now with mounting-brackets
- pluggable receiver- and telemetry-cables with JST-socket
- New 32-Bit Processor
- telemetry
- current-limiting
- easy setup of parameters straight in your transmitter (Graupner, Jeti and Mikado VBC)
- Update and advanced-Setup via PC-Software (optional USB-adapter necessary)
- RPM-limit: 240.000 RPM (2-pole motor)

supported telemetry-protocols:
  • Graupner HoTT V4
  • Jeti ExBUS
  • Multiplex Sensor BUS V2
  • Mikado Vbar Control
  • YGE-Protocol for more telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL



All usual informations as current, voltage, capacity, RPM, temperature etc. will be transferred to your transmitter. The amount of data and the characterisation depends on your transmitter/receiver.

NEW!

YGE 95LVT & 135LVT

supported telemetry-protocols:
  • Graupner HoTT V4
  • Jeti ExBUS
  • Multiplex Sensor BUS V2
  • Mikado Vbar Control
  • YGE-Protocol for more telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL



All usual informations as current, voltage, capacity, RPM, temperature etc. will be transferred to your transmitter. The amount of data and the characterisation depends on your transmitter/receiver.

Telemetry-speedcontroller now programmable via Graupner HoTT V4 transmitter

graupner+yge
Our LVT- and future HVT-speedcontrollers can now be programmed with the telemetry menu of the Graupner- transmitter.
You can find the most important parameters here clearly layed out on 2 pages.
You can also choose one of the modes (the controller will be restarted).

Please note:

  • Controller- firmware >V1.03240 required.
  •  In order to use the Graupner- telemetry and to program the transmitter it is necessary to once choose "HoTT V4" as the telemetry- protocol in the PC- software.
  • In case of update requests, please use our contact form and state the serial number of your controller, which can be seen in the PC- software when the controller is connected. Subsequently we will send you an update-file. With the firmware-updater you can manually choose the file and update the controller.

yge+vbar

Please note:

  • Controller-firmware >V1.03240 required.
  • All functions can only be used with Vbar Neo (controller setup in the transmitter). Only telemetry will also function with older Vbars.
  • In order to use the VBC-telemetry and programming in the transmitter it is necessary to once choose "Mikado" as the telemetry protocol in the PC software.
  • In case of update requests, please use our contact form and state the serial number of your controller, which can be seen in the PC-Software when the controller is connected. Subsequently we will send you an update-file. With the firmware-updater you can manually choose the file and update the controller.

NEW: Now with Telemetry!

supported telemetry-protocols:
  • Graupner HoTT V4
  • Jeti ExBUS
  • Multiplex Sensor BUS V2
  • Mikado Vbar Control
  • YGE-Protocol for more telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL

All usual informations as current, voltage, capacity, RPM, temperature etc. will be transferred to your transmitter. The amount of data and the characterisation depends on your transmitter/receiver.

Mode-Programming

From now on, all our controllers have the new "mode-programming".

The parameters which you previously had to program seperately with the ProgCard  will be set automatically to ideal standard-values and the throttle-endpoints will be set properly for your transmitter.

It is faster, easier and safer!

You can choose among 5 different modes:

Mode 1

Vbar/external Governor (Heli)

Mode 2

Governor (Heli)

Mode 3

Governor Store (Heli)

Mode 4

Motor plane with brake (Glider)

Mode 5

Motor plane without brake

We recommend to complete the mode-setup first.

The pre-set parameters usually fit all current standard setups.

If you have a special motor (inrunner for example), you can use the ProgCard afterwards to change the timing.

The following ESC's already have the mode-programming:

YGE 18 & 30 (since mid 16)

YGE 40 & 60 (since V5)

YGE 90LV, 120LV &120LVK (since V2)

YGE 60HV (Software 52,54)

YGE 90HV (Software 52,54)

YGE 120HV, 160HV, 200HV (since V5 --> S52,54)

If you are not sure whether your speed-controller has the new mode-programming,

take a look at the attached manual. There you will find the section "mode-programming".
