Low Voltage (LV)

YGE 8S

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 2 to 4s LiPo, with under voltage protection by power reduction.
  • disconnectable under voltage detection.
  • switching BEC: 5.5V, 2A continuous, 4A peak.
  • Speed regulation (Governor mode).
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz
  • Speed limit: 240,000 RPM (2-Pole motors)
  • Temperature and overload warning
  • Overall dimensions: 42 x 24 x 6 mm
  • Weight  without wires 11g, with wires: 14g
  • programming with Mode - setup or with the ProgCard II or III

Price: 34,00 €

PDF - MANUAL

YGE 12S

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 2 to 3s LiPo, with under voltage protection by power reduction.
  • disconnectable under voltage detection.
  • BEC: 5V,  2A.
  • Speed regulation (Governor mode).
  • Soft start.
  • Automatic or 6 step adjustable timing.
  • 5 steps adjustable regular back EMF brake.
  • Switching rate: 8 to 16 kHz
  • Speed limit: 240,000 RPM (2-Pole motors)
  • Temperature and overload warning
  • Overall dimensions: 25 x 17 x  5 mm
  • Weight  without / with wires: 2,9 / 6g.
  • Programming with the ProgCard II or III

Price: 39,00 €

PDF - MANUAL

YGE 18

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 2 to 4s LiPo, with under voltage protection by power reduction.
  • disconnectable under voltage detection.
  • switching BEC: 5.5V, 2A continuous, 4A peak.
  • Speed regulation (Governor mode).
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz
  • Speed limit: 240,000 RPM (2-Pole motors)
  • Temperature and overload warning
  • Overall dimensions: 42 x 24 x 6 mm
  • Weight  without wires 11g, with wires: 14g
  • programming with Mode - setup or with the ProgCard II or III

Price: 59,00 €

PDF - MANUAL

YGE 30

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 2 to 4s LiPo, with under voltage protection by power reduction.
  • disconnectable under voltage detection.
  • switching BEC: 5.5V, 2A continuous, 4A peak.
  • Speed regulation (Governor mode).
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz
  • Speed limit: 240,000 RPM (2-Pole motors)
  • Temperature and overload warning
  • Overall dimensions: 48 x 24 x 6 mm
  • Weight  without /with  wires 11g / 21g.
  • programming with Mode - setup or with the ProgCard II or III

Price: 69,00 €

PDF - MANUAL

YGE 40

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 2 to 6s LiPo, with under voltage protection by power reduction.
  • Disconnectable under voltage detection.
  • Switching BEC: 5.5V,  3A continuous, 5A peak.
  • Speed regulation (Governor mode).
  • RPM-output for external governors (for example Vbar-Gov)
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz.
  • Speed limit: 240,000 RPM (2-Pole motors).
  • Temperature and overload warning.
  • Anti sparkling circuit: reduces connection sparkles.
  • programming with Mode - setup or with the ProgCard II or III
  • Overall dimensions: 62 x 26 x 8 mm
  • Weight  without /with  wires 19g / 37g.

Price: 99,00 €

PDF - MANUAL

YGE 60

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 2 to 6s LiPo, with under voltage protection by power reduction.
  • Disconnectable under voltage detection.
  • Switching BEC: 5.5V,  3A continuous, 5A peak.
  • Speed regulation (Governor mode).
  • RPM-output for external governors (for example Vbar-Gov)
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz.
  • Speed limit: 240,000 RPM (2-Pole motors).
  • Temperature and overload warning.
  • Anti sparkling circuit: reduces connection sparkles.
  • programming with Mode - setup or with the ProgCard II or III
  • Overall dimensions: 62 x 26 x 8 mm
  • Weight  without /with  wires 20g / 38g.

Price: 119,00 €

PDF - MANUAL

YGE 90LV

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 3 to 6s LiPo, with under voltage protection by power reduction.
  • disconnectable under voltage detection.
  • switching BEC: 5.7V / 7.4V / 8.0V,  8A continuous, 18A peak.
  • 2 BEC cabels (Master and Slave)
  • Speed regulation (Governor mode).
  • RPM-output for external governors (for example Vbar-Gov)
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz.
  • Speed limit: 240,000 RPM (2-Pole motors).
  • Temperature and overload warning.
  • Anti sparkling circuit: reduces connection sparkles.
  • programming with Mode - setup or with the ProgCard II or III
  • Overall dimensions: 72 x 32 x 13 mm
  • Weight  without /with  wires 53g / 83g.

Price: 159,00 €

PDF - MANUAL

YGE 120LV

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 3 to 6s LiPo, with under voltage protection by power reduction.
  • disconnectable under voltage detection.
  • switching BEC: 5.7V / 7.4V / 8.0V,  8A continuous, 18A peak.
  • 2 BEC cabels (Master and Slave)
  • Speed regulation (Governor mode).
  • RPM-output for external governors (for example Vbar-Gov)
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz.
  • Speed limit: 240,000 RPM (2-Pole motors).
  • Temperature and overload warning.
  • Anti sparkling circuit: reduces connection sparkles.
  • programming with Mode - setup or with the ProgCard II or III
  • Overall dimensions: 72 x 32 x 13 mm
  • Weight  without /with  wires 55g / 85g.

Price: 189,00 €

PDF - MANUAL

YGE 120LVK

Technical Specifications
  • The specified current is the maximum continuous full power current with adequate cooling.
  • 3 to 6s LiPo, with under voltage protection by power reduction.
  • disconnectable under voltage detection.
  • switching BEC: 5.7V / 7.4V / 8.0V,  8A continuous, 18A peak.
  • 2 BEC cabels (Master and Slave)
  • Speed regulation (Governor mode).
  • RPM-output for external governors (for example Vbar-Gov)
  • Soft start.
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing.
  • 3 steps adjustable back EMF brake.
  • Switching rate: 8 to 16 kHz.
  • Speed limit: 240,000 RPM (2-Pole motors).
  • Temperature and overload warning.
  • Anti sparkling circuit: reduces connection sparkles.
  • programming with Mode - setup or with the ProgCard II or III
  • Overall dimensions: 72 x 32 x 19 mm
  • Weight  without /with  wires 68g / 98g.

Price: 199,00 €

PDF - MANUAL
