High Voltage (HV)

Important!

you can preprogram the HVT-series with the mode-programming. For the full range of programmable functions, the optionally available USB-adapter is needed.

The ProgCard is not compatible with the HVT-series!

YGE 165HVT

Technical Specifications
  • "T" for Telemetry. following protocols are currently compatible: Mikado VBC, Graupner HoTT V4, Jeti ExBUS, Multiplex Sensor BUS V2, YGE-protocol for different telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL

  • Update capable (optional USB-Adapter available)

  • entirely overhauled hard- and software (32-bit)
  • the PWM-frequency will be set automatically to the requirements of the motor
  • The specified current is the maximum continuous full power current
  • 6 to 14s LiPo, incl under voltage protection by power reduction
  • Current limiting
  • Disconnectable under voltage detection
  • Electronic speed control (Governor- mode)
  • Soft start
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing
  • Adjustable EMK brake
  • F3A(Acro brake (brake force control infinitely adjustable)
  • Frequency: 16 to 32 kHz
  • Speed limit: 240.000 rpm (2- Poles)
  • Temperature and overload warning
  • Anti- flash: decreases the closing spark
  • Basic -Programming with mode programming
  • Fine adjustment and selection of telemetry log with the PC Setup
  • Suitable USB-adapter optionally available

PDF - MANUAL

Download

YGE Aureus 135

+BEC 10A/25A

Technical Specifications
  • BEC 5,0V - 8,4V
  • BEC 10A continuous, 25A Peak
  • "T" for Telemetry. following protocols are currently compatible: Mikado VBC, Graupner HoTT V4, Jeti ExBUS, Multiplex Sensor BUS V2, YGE-protocol for different telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL

  • Update capable (optional USB-Adapter available)

  • entirely overhauled hard- and software (32-bit)
  • the PWM-frequency will be set automatically to the requirements of the motor
  • The specified current is the maximum continuous full power current
  • 6 to 12s LiPo, incl under voltage protection by power reduction
  • Current limiting
  • Disconnectable under voltage detection
  • Electronic speed control (Governor- mode)
  • Soft start
  • super soft startup for scale-helicopters possible (60 sec.)
  • Active free-wheel, allowing unlimited part load operation
  • Automatic or 6 step adjustable timing
  • Adjustable EMK brake
  • F3A(Acro brake (brake force control infinitely adjustable)
  • Frequency: 16 to 32 kHz
  • Speed limit: 240.000 rpm (2- Poles)
  • Temperature and overload warning
  • Anti- flash: decreases the closing spark
  • Basic -Programming with mode programming
  • Fine adjustment and selection of telemetry log with the PC Setup
  • Suitable USB-adapter optionally available
  • dimensions (mm): 82 x 43,5 x 26
  • weight without/with cables: 122g/178g

PDF - MANUAL

Download

YGE 205HVT

+BEC 12A/30A

Technical Specifications
  • BEC 5,0V - 8,4V
  • BEC 12A continuous, 30A Peak
  • "T" for Telemetry. following protocols are currently compatible: Mikado VBC, Graupner HoTT V4, Jeti ExBUS, Multiplex Sensor BUS V2, YGE-protocol for different telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL

  • Update capable (optional USB-Adapter available)

  • entirely overhauled hard- and software (32-bit)
  • the PWM-frequency will be set automatically to the requirements of the motor
  • The specified current is the maximum continuous full power current
  • 6 to 14s LiPo, incl under voltage protection by power reduction
  • Current limiting
  • Disconnectable under voltage detection
  • Electronic speed control (Governor- mode)
  • Soft start
  • super soft startup for scale-helicopters possible (60 sec.)
  • Active free-wheel, allowing unlimited part load operation
  • Automatic or 6 step adjustable timing
  • Adjustable EMK brake
  • F3A(Acro brake (brake force control infinitely adjustable)
  • Frequency: 16 to 32 kHz
  • Speed limit: 240.000 rpm (2- Poles)
  • Temperature and overload warning
  • Anti- flash: decreases the closing spark
  • Basic -Programming with mode programming
  • Fine adjustment and selection of telemetry log with the PC Setup
  • Suitable USB-adapter optionally available
  • dimensions (mm): 84 x 56 x 31
  • weight without/with cables: 219g/287g

PDF - MANUAL

Download

YGE 90HVT Opto

Technical Specifications
  • "T" for Telemetry. following protocols are currently compatible: Mikado VBC, Graupner HoTT V4, Jeti ExBUS, Multiplex Sensor BUS V2, YGE-protocol for different telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL

  • Update capable (optional USB-Adapter available)

  • entirely overhauled hard- and software (32-bit)
  • the PWM-frequency will be set automatically to the requirements of the motor
  • The specified current is the maximum continuous full power current
  • 4 to 12s LiPo, incl under voltage protection by power reduction
  • Current limiting
  • Disconnectable under voltage detection
  • Electronic speed control (Governor- mode)
  • Soft start
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing
  • Adjustable EMK brake
  • F3A(Acro brake (brake force control infinitely adjustable)
  • Frequency: 16 to 32 kHz
  • Speed limit: 240.000 rpm (2- Poles)
  • Temperature and overload warning
  • Anti- flash: decreases the closing spark
  • Basic -Programming with mode programming
  • Fine adjustment and selection of telemetry log with the PC Setup
  • Suitable USB-adapter optionally available

PDF - MANUAL

Download

YGE 120HVT Opto

Technical Specifications
  • "T" for Telemetry. following protocols are currently compatible: Mikado VBC, Graupner HoTT V4, Jeti ExBUS, Multiplex Sensor BUS V2, YGE-protocol for different telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL

  • Update capable (optional USB-Adapter available)

  • entirely overhauled hard- and software (32-bit)
  • the PWM-frequency will be set automatically to the requirements of the motor
  • The specified current is the maximum continuous full power current
  • 4 to 12s LiPo, incl under voltage protection by power reduction
  • Current limiting
  • Disconnectable under voltage detection
  • Electronic speed control (Governor- mode)
  • Soft start
  • Active free-wheel, allowing unlimited part load operation.
  • Automatic or 6 step adjustable timing
  • Adjustable EMK brake
  • F3A(Acro brake (brake force control infinitely adjustable)
  • Frequency: 16 to 32 kHz
  • Speed limit: 240.000 rpm (2- Poles)
  • Temperature and overload warning
  • Anti- flash: decreases the closing spark
  • Basic -Programming with mode programming
  • Fine adjustment and selection of telemetry log with the PC Setup
  • Suitable USB-adapter optionally available

PDF - MANUAL

Download

YGE 200FAI Opto

Only for Hotliner & Pylonracer (F5B-Competition)

Technical Specifications
  • only limited partial-load suitable
  •  "T" for Telemetry. following protocols are currently compatible: Mikado VBC, Graupner HoTT V4, Jeti ExBUS, Multiplex Sensor BUS V2, YGE-protocol for different telemetry-connections for example via YGE TexY (Futaba, Spektrum, FrSky), MSH Brain 2 or Spirit FBL
  • Update capable (optional USB-Adapter available)

  • entirely overhauled hard- and software (32-bit)
  • the PWM-frequency will be set automatically to the requirements of the motor
  • The specified current is the maximum continuous full power current
  • 4 to 12s LiPo, incl under voltage protection by power reduction
  • Current limiting
  • Disconnectable under voltage detection
  • Automatic or 6 step adjustable timing
  • Adjustable EMK brake
  • F3A(Acro brake (brake force control infinitely adjustable)
  • Frequency: 16 to 32 kHz
  • Speed limit: 240.000 rpm (2- Poles)
  • Temperature and overload warning
  • Anti- flash: decreases the closing spark
  • Basic -Programming with mode programming
  • Fine adjustment and selection of telemetry log with the PC Setup
  • Suitable USB-adapter optionally available

PDF - MANUAL

Download
